What are the reasons for oil leakage in planetary gear reducers?
Planetary gear reducers may experience oil leakage during use; When oil leakage occurs, it will not only affect the normal operation of the equipment, but also cause insufficient lubricating oil, making it difficult for the gears and bearings of the planetary gear reducer to receive good lubrication. In severe cases, it may lead to erosive damage to the gears and bearings.

So, what are the reasons for oil leakage in planetary gear reducers? Experienced gearbox manufacturers come to reveal for you!

In some cases, unreasonable design or poor manufacturing process of planetary gear reducers may lead to oil leakage faults; The unreasonable design of planetary gear reducers is mainly manifested in the lack of oil return grooves on the housing, where lubricating oil accumulates at the end cover, joint surface, and shaft seal, and the pressure difference causes leakage from the clearance position to the outside;

The gearbox is not equipped with a ventilation cover, so it cannot be evenly pressurized, which will cause the pressure inside the chassis to continue to rise, ultimately leading to oil leakage; The material used for the inspection hole cover plate is too thin, which is prone to deformation after installing the bolt, resulting in uneven joint surfaces and ultimately leading to oil leakage at the contact gap.

During the installation process of planetary gear reducers, if the seals are not installed correctly or the fasteners are not tightened to the specified torque, it may also cause oil leakage faults.

The working environment of planetary gear reducers can also have a significant impact on their operation. For example, rapid changes in ambient temperature can cause temperature differences between the inside and outside of planetary gear reducers, leading to thermal expansion and contraction of metal components and sealing materials, which in turn can damage the sealing effect and ultimately result in oil leakage faults.

Sometimes, due to environmental limitations, planetary gear reducers may experience blockages in the ventilation system or poor ventilation. Once these problems occur, it can cause gas to be generated inside the reducer due to operation, which cannot be discharged normally. This can lead to a rapid increase in temperature inside the gearbox, greatly increasing the internal air pressure. Under the pressure, lubricating oil inside the gearbox may leak and overflow from the gaps of the equipment.

The precision requirements for machining and installation of planetary gear reducers are relatively high. Generally speaking, when the reducer is started, it needs to bear a huge dynamic load. If the installation precision of the equipment does not meet the relevant standard requirements, it may cause the bolts of the reducer base to loosen, leading to wear of the sealing rings at the high and low speed shaft holes of the reducer and increased vibration of the machine body, thereby causing lubricating oil leakage.
